Refine Search > SLIDE > JS2235S
Product Info
| Part Number |
JS2235S
|
| Type |
Horizontal Type |
Product Detail
| Operating force |
200 ± 100 gf |
| Operating direction |
Top push, Side push |
Side slide |
|
Horizontal, Vertical
|
Horizontal |
| Slider Color |
black |
| Operating life |
10000 |
| Water Proof |
|
| Travel |
Full |
2.0mm |
| Operating temperature range |
-10 ~ 60 °C |
| Rating |
DC 6V 0.3A |
| Dimensions |
9.0mm * 3.5mm |
| Length |
5.5mm |
| Timing |
Non shorting |
| Circuit |
2C - 2P |
| Electrical performance |
Insulation resistance
|
100 |
| Voltage proof |
100 |
| Contact resistance |
100 |
| Environmental performance |
Cold
|
-25 ± 2 °C 96Hr |
|
Dry
|
85 ± 2 °C 96Hr |
|
Damp
|
60 ± 2 °C 96Hr |
Package Info
| Number of Packages |
1000 |
| Packing Type |
Reel |
| Number of Packages (1c/t) |
|
| Package Measurements (mm) |
480 * 290 * 370 |
Product floor plan
